Kubota GL11000 Diesel Generator – Lowboy II Series
Compact, Reliable, and Eco-Friendly Power Solution
The Kubota GL11000 Diesel Generator, part of the renowned Lowboy II Series, is engineered to deliver reliable, efficient, and clean power in a compact design. Ideal for various commercial applications, this generator is built with Kubota’s advanced technology to minimize emissions, reduce noise levels, and ensure user-friendly maintenance.
Key Features of Kubota GL11000 Generator
1. Space-Saving Design
- Compact Build: Designed to have the minimum possible height while using vertical diesel engines.
- Direct Coupling: The engine crankshaft is directly coupled with the cooling fan, reducing space requirements and power loss.
2. Dependable Power Supply
- Direct-Coupled Generator and Engine: Ensures reliable power output with minimal energy loss.
- Skewed Rotor & Damper Winding: Reduces waveform distortion and regulates voltage fluctuations for consistent performance.
3. Environmentally Friendly
- E-TVCS Combustion System: Minimizes HC, CO, and soot emissions, complying with USA EPA Tier 4 standards.
4. Low Noise Levels
- Large Capacity Radiator: Reduces fan-related noise.
- Built-In Muffler: Minimizes exhaust noise.
- Longer Air Cleaner Hose: Lowers air suction noise.
- Optimized Inlet Vent Design: Reduces enclosure noise.
5. Extended Operation Time
- Fuel Tank Capacity: 7.4 gallons (28L) supports up to 10.4 hours of continuous operation at 50% load.
6. Easy Maintenance
- One-Side Maintenance Access: Oil, fuel, and battery checks are conveniently located on one side.
- Larger Oil Pan: Extends oil change intervals, reducing operational costs.
- Double-Element Air Cleaners: Ideal for dusty environments.
7. Enhanced Safety Features
- Double Circuit Breakers: Prevent overcurrent damage.
- Protective Covers: Safeguard moving parts.
- Automatic Shutdown System: Prevents engine damage due to high temperature or low oil pressure.
- Start Safety Relay: Prevents accidental starter engagement after engine startup.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | GL11000 |
| Manufacturer | Kubota |
| Country of Origin | No (Not Made in USA) |
| Rated Watts | 11kW |
| Voltage | 120/240V Single Phase |
| Enclosure Material | Steel |
| UL Listed | No |
| Noise Level | 68 dB(A) @ 23 ft. |
| Type | Commercial Mobile Generator |
| Starting System | Electric Start |
| Low Oil Alert | Yes |
| Fuel Gauge | Visual Tube |
| Hour Meter | Yes |
| Battery Requirement | 12V 36Ah (55B24R) |
| Weight | 650 lbs |
| Dimensions | 50.4L x 24.3W x 27.5H |
| Warranty | 2-Year Limited Warranty |
Engine Details
| Engine Specification | Details |
|---|---|
| Engine Brand | Kubota D722 |
| Engine Type | 3-Cylinder, 16.3 HP |
| Engine RPM | 3600 RPM |
| Cooling System | Liquid Cooled |
Fuel System
| Fuel Specification | Details |
|---|---|
| Fuel Type | Diesel |
| Fuel Tank Size | 7.4 gallons (28L) |
| Run Time (50% Load) | 10.4 hours |
Receptacle Details
| Receptacle Type | Quantity |
|---|---|
| 5-20R (GFCI) | 2 |
| L5-30R | 1 |
| L6-30R | 1 |
| CS6369 (50 Amp) | 1 |
Ease of Transport and Installation
- Forklift Openings: Simplify transportation.
- One-Point Lifting Eye: Enhances mobility.
- Remote Control Kit: Optional for added convenience.
- ATS Access Terminals: Simplifies wiring for automatic transfer switches.
Why Choose the Kubota GL11000 Diesel Generator?
- Proven Reliability: Backed by Kubota’s engineering excellence.
- Lower Operating Costs: Longer maintenance intervals and efficient fuel consumption.
- Versatile Applications: Suitable for commercial, industrial, and backup power needs.
- User-Friendly Design: Easy maintenance and operation.
